Lenovo ThinkPad T540p W540 W541 PCB: 12291-1
SKU: 12379
Schematic diagrams for Laptops Lenovo ThinkPad T540p / ThinkPad W540 Project: LKM-1 WS
- Manufacturer: Wistron
- SKU: 12379
- Unit: pcs
- Size: 3.25Mb
- Availability: In stock
- Tags:
4.50eur
3.75eur
Schematic diagrams for Laptops Lenovo ThinkPad T540p / Lenovo ThinkPad W540 / Lenovo ThinkPad W541
Project: Wistron ' LKM-1 WS '
Schematic diagrams for motherboard marked LKM-1 WS MB 12291-1
Format: PDF
Total pages: 105
+ BoardView Rev: 1
The program for viewing is attached.
BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
