Lenovo ThinkPad P14s P15s T14 T15 Gen 1

Rating: 5.0/4
 5.25eur
  • Manufacturer: Lenovo
  • CPU: Intel Comet Lake
  • VGA: Nvidia N19M / UMA
  • RAM: DDR4
  • SKU: 12513
  • Unit: pcs
  • Size: 5.17Mb
  • Availability: In Stock
    • Tags: Gen 1, P14s, T15, P15s, thinkpad, Lenovo, T14
Compare

Schematic diagrams for Laptops Lenovo ThinkPad P14s Gen 1 / ThinkPad P15s Gen 1 / ThinkPad T14 Gen 1 / ThinkPad T15 Gen 1

Project: NM-C931   Rev: 1.0

Schematic diagrams for PCB marked GT4A0/GT5A1/GP4A0/GP5A1/GT4A2 NM-C931

Format: PDF

Total pages: 125

+ BoardView   Rev: 1.0   ( shows the values / labeling of the components )

The program for viewing is attached.

Added by: Dr-laptop, Wednesday, 26.10.2022
