Acer Swift 1 SF114-34

5.0/3
Compare
SKU: 00635
Schematic diagrams for Laptop Acer Swift 1 SF114-34 Project: Huaqin NB2950
  • Manufacturer: Huaqin
  • CPU: Intel Jasper Lake
  • VGA: UMA
  • RAM: DDR4
  • SKU: 00635
  • Unit: pcs
  • Size: 2.84Mb
  • Availability: In stock
  • Tags: Swift, Acer, SF114-34, Huaqin
4.50eur

Schematic diagrams for Laptop Acer Swift 1 SF114-34

Project: Huaqin NB2950

Schematic diagrams for motherboard marked NB2950_MB_V3 and similar

Format: PDF

Total pages: 110

+ BoardView   Rev: 3

Format: CAD

The program for viewing is attached.



BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
