BoardView for Laptops ASUS ROG Strix G513RC / G513RE / G713RC / G713RE
- Manufacturer: ASUS
- CPU: AMD Rembrandt H
- VGA: Nvidia GN20
- RAM: DDR5
- SKU: 03660
- Unit: pcs
- Size: 430.8Kb
- Availability: In stock
- Tags:
5.25eur
BoardView for Laptops ASUS ROG Strix G15 G513RC / G513RE & ASUS ROG Strix G17 G713RC / G713RE
Project: G513R-PMV-VGT
BoardView for motherboard marked G513R-PMV-VGT 6050A3348203-MB-A01
Two sides.
Format: CAD
Shows positional designations, electrical circuits between components, and other details.
The program for viewing is attached.
BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
