Lenovo IdeaCentre AiO 5 24IMB05 5-24IMB05

Name: Lenovo IdeaCentre AiO 5 24IMB05 5-24IMB05
Brand: Lenovo
SKU: 12590
Price: 5.25 EUR
Availability: InStock
Rating: 5.0 (1 reviews)

Rating: 5.0/1

5.25eur

Manufacturer: Lenovo
CPU: Intel Socket 1200
VGA: Nvidia N17S / UMA
RAM: DDR4
SKU: 12590
Unit: pcs
Size: 4.53Mb
Availability: In Stock

24IMB05, IdeaCentre, AIO, Lenovo, All-in-One PC

Description
Images

Schematic diagrams for All-in-One PCs Lenovo IdeaCentre 5 24IMB05 / Lenovo IdeaCentre 5-24IMB05

Project: Lenovo IB460SL1

Schematic diagrams for PCB marked IB460SL1 A550-24IMB

Format: PDF

Total pages: 99

+ BoardView ( shows the values / labeling of the components )

The program for viewing is attached.

Added by: Dr-laptop, Sunday, 18.02.2024
