ASUS VivoBook S532F S532FL S532FLC PCB: X532FLC

5.0/1
Compare
SKU: 03683
BoardView for Laptops ASUS VivoBook S15 S532F / S532FL / S532FLC Project: ASUS X532FLC
  • Manufacturer: ASUS
  • CPU: Intel Comet Lake
  • VGA: Nvidia N17S / UMA
  • RAM: DDR4
  • SKU: 03683
  • Unit: pcs
  • Size: 128.3Kb
  • Availability: In stock
  • Tags: S532FLC, S532FL, VivoBook, ASUS, S532F
4.50eur

BoardView for Laptops ASUS VivoBook S15 S532F / ASUS VivoBook S15 S532FL / ASUS VivoBook S15 S532FLC

Project: ASUS X532FLC   Rev: 2.0

BoardView for motherboard marked X532FLC MAIN BOARD REV. 2.0

Two sides.

Format: FZ   ( shows the values / labeling of the components )

Shows positional designations, electrical circuits between components, and other details.

The program for viewing is attached.



BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
