Schematic diagrams for Laptop Lenovo IdeaPad Y500 Project: Compal LA-8692P
- Manufacturer: Compal
- CPU: Intel Socket 989
- VGA: Nvidia N13P
- RAM: DDR3
- SKU: 12146
- Unit: pcs
- Size: 3.82Mb
- Availability: In stock
- Tags:
4.50eur
Schematic diagrams for Laptop Lenovo IdeaPad Y500
Project: Compal LA-8692P
Schematic diagrams for motherboard marked QIQY6 LA-8692P
Format: PDF
+ Sub-boards schematic diagrams ( including the second VGA module )
Total pages: 94
+ BoardView Rev: 1.0
The program for viewing is attached.
BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
