HP 250 G7 255 G7 HP 15-db 15t-db 15-dx series
SKU: 08488
Schematic diagrams for Laptops HP 250 G7 / HP 255 G7 / HP 15-db / HP 15t-db / HP 15-dx series
- Manufacturer: Compal
- CPU: AMD Picasso / Raven Rigge
- GPU: AMD R17M / UMA
- RAM: DDR4
- SKU: 08488
- Unit: pcs
- Size: 3.30Mb
- Availability: In stock
- Tags:
5.25eur
4.50eur
Schematic diagrams for Laptops HP 250 G7 / 255 G7 series / HP 15-db / HP 15t-db / HP 15-dx series
Project: Compal LA-G07JP
Schematic diagrams for motherboard marked FPP55 LA-G07JP
Format: PDF
Total pages: 50
+ BoardView Rev: 2.0
Format: CAD
The program for viewing is attached.
BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
