Schematic diagrams for Laptops Lenovo ThinkPad E14 Gen 5 / E16 Gen 1 Project: KE452/KE612 NM-F351
- Manufacturer: Lenovo
- CPU: AMD Barcelo R
- VGA: UMA
- RAM: DDR4
- SKU: 12648
- Unit: pcs
- Size: 1.76Mb
- Availability: In stock
- Tags:
7.00eur
Schematic diagrams for Laptops Lenovo ThinkPad E14 Gen 5 / Lenovo ThinkPad E16 Gen 1
Project: NM-F351 Rev: 1.0
Schematic diagrams for motherboard marked KE452/KE612 NM-F351 Rev:1.0
Format: PDF
Total pages: 54
+ BoardView Rev: 1.0
Format: CAD full ( shows the values / labeling of the components )
The program for viewing is attached.
BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
