Lenovo IdeaPad Slim 5 16IMH9 PCB: LA-N191P
SKU: 12652
Schematic diagrams for Laptop Lenovo IdeaPad Slim 5 16IMH9 Project: ILS4M LA-N191P
- Manufacturer: Compal
- CPU: Intel Meteor Lake H
- GPU: UMA
- RAM: LPDDR5X
- SKU: 12652
- Unit: pcs
- Size: 2.69Mb
- Availability: In stock
- Tags:
5.25eur
4.50eur
Schematic diagrams for Laptop Lenovo IdeaPad Slim 5 16IMH9
Project: Compal LA-N191P Rev: 1A
Schematic diagrams for motherboard marked ILS4M LA-N191P Rev:1A
Format: PDF
Total pages: 150
BoardView in CAD format is available for quick order (not included in the price, price on request)
BoardView is a layout of components on a printed circuit board (PCB) with a wide range of repair functions.
